VS3000

The VS3000 chipset series are highly integrated IC’s with best-in-class long distance multimedia distribution in the professional audio-video market. Supporting HDBaseT 3.0, it is the only truly uncompressed solution for HDMI 2.0 4K@60 4:4:4 long reach connectivity with zero-latency.

HDMI 2.0

HDCP

I2S-4

S/PDIF

eARC

1Gbps

Ethernet

USB 2.0

I2C

UART

CIR

Power

Uncompressed

High bandwidth, zero latency – 16Gbps/2Gbps for up to 100m/328 ft.

Convergence

Video (Uncompressed HDMI 2.0, HDCP), Audio (I2S-4, S/PDIF, eARC), Ethernet (1Gbps), USB 2.0, Controls (I2C, UART, CIR), and Power over a single Category cable

Flexible network architecture

Supporting point-to-point, multi-stream, daisy chain, and ring topologies.

Market Applications

Product Series

VS3000

Uncompressed 4K@60Hz 4:4:4, converging all interfaces

Uncompressed 4K@60Hz 4:4:4, converging all interfaces

Key Specs:

Bandwidth

18Gpbs/2Gbps

Reach

100m

Channel

Cat

VS3100

Cost-optimized uncompressed 4K@60Hz 4:4:4, excluding USB

Cost-optimized uncompressed 4K@60Hz 4:4:4, excluding USB

Key Specs:

Bandwidth

18Gpbs/2Gbps

Reach

100m

Channel

Cat

VS300R

Cost-optimized uncompressed 4K@60Hz 4:4:4, excluding Ethernet

Cost-optimized uncompressed 4K@60Hz 4:4:4, excluding Ethernet

Key Specs:

Bandwidth

18Gpbs/2Gbps

Reach

40-70m

Channel

Cat

VS310R

Cost-optimized uncompressed 4K@60Hz 4:4:4, excluding USB & Ethernet

Cost-optimized uncompressed 4K@60Hz 4:4:4, excluding USB & Ethernet

Key Specs:

Bandwidth

18Gpbs/2Gbps

Reach

40-70m

Channel

Cat

Download

VS3000 Series Product Specs
